Tubes & Boards
Scaffolding Tubes And Boards
Factory-direct category page for scaffold tubes and galvanized boards used in bulk container orders for distributors, contractors, and project procurement teams.
B2B category page for edge protection systems, built around perimeter safety supply for distributors and contractors who need real technical and packing information before quotation.
Buyer fit
Distributor and contractor RFQs
Quote mode
Quantity, pack, and spec first
Factory angle
OEM and export discussion welcome
Priority inquiry email
Use this category page to narrow the commercial scope, then move straight into quantity, packing, and destination-market discussion.
Technical definition
Edge protection systems are temporary safety barriers installed at the perimeter of elevated work platforms or open edges to prevent falls, classified under EN 13374 into three performance classes: Class A (static loads on flat surfaces up to 10°), Class B (low dynamic loads on surfaces up to 30°), and Class C (high dynamic loads on steep surfaces up to 60°). A typical system consists of vertical posts (900–1200 mm above deck level), horizontal guardrails, an intermediate rail, and a toe board (minimum 150 mm height per OSHA 1926.502). Surface finishes include powder coating for visibility and corrosion resistance in outdoor construction environments.
Engineering-style data sheet
| Item Code | Size (mm) | Weight (kg) | Surface Finish | Standard | Qty / Pack |
|---|---|---|---|---|---|
| EP-POST-1200 | 1200 mm post | 4.2 kg | Powder coated | Factory test available | 100 pcs / pallet |
| EP-RAIL-2600 | 2600 mm rail | 7.9 kg | Powder coated | Factory test available | 50 pcs / pallet |
| EP-TOE-2600 | 2600 mm toe board | 5.1 kg | Powder coated | Factory test available | 60 pcs / pallet |
Visual review
Category inquiry checklist
Related categories
Factory-direct category page for scaffold tubes and galvanized boards used in bulk container orders for distributors, contractors, and project procurement teams.
Wholesale category page for scaffolding couplers and clamps, focused on forged and pressed fitting demand for distributors and project-based container procurement.
Category page for adjustable base jacks and related support hardware, built for buyers who need engineering-style dimensions, weight, finish, and pack data before inquiry.
If the requirement crosses multiple categories, upload the material list on the BOM page or send one consolidated inquiry to [email protected]. That is usually faster than splitting a complex RFQ too early.
